顶部驱动钻井装置
顶部驱动钻井装置
顶部驱动钻井装置，是取代传统钻进设备的新型钻井装置.顶驱集机、电、液于一体，结构复杂，多学科交叉，是当今石油钻井领域的重大技术之一，被誉为钻井装备领域的第三次革命。代表着21世纪石油钻井行业和机电液一体化石油钻井专用设备的最高水平和发展方向，已经成为国际钻井行业的标准配置。适用于丛式定向钻井、大斜度井、水平井，更适用于深井、超深井。
天意人专门致力于顶部驱动钻井装置的研发、设计、制造和服务，拥有专业的技术团队和服务团队。现已拥有14项国家专利，完全拥有自主知识产权，产品技术性能达到了国际先进水平，成为国内钻井应用的主力品牌。广泛应用于中石油、中石化、中海油、英荷皇家壳牌、法国道达尔、美国远东能源以及俄罗斯、尼日尔、苏丹、伊朗、缅甸等油气田项目。
技术特点:
●机电液一体化的控制技术，变频器交流输出参数与电机的特性要求相匹配， 自行编制的PLC程序可根据用户要求进行设计，具有保护和互锁功能，更加符合钻井工况。
●回转头只用两个油道给倾斜油缸供油，实现吊环的前倾和后摆，而且每个油道均为双密封，泄漏事故率大大降低，提高了设备使用的可靠性；在起下钻时允许回转头随钻具旋转，方便事故处理。
●采用双负荷通道，即钻井时减速箱轴承承载，在起下钻时回转头轴承承载，提高了轴承、主轴的使用寿命和抗钻柱纵向震动能力。
●顶驱采用L型背钳，方便更换钳头、钳牙和上IBOP、下IBOP及保护短接。
●液压泵在钻进和定向过程中可以关闭，延长泵的使用寿命。即使液压系统停止工作，也可进行钻进、划眼作业。
●集成液压系统连同油箱集成于顶驱本体之上，系统发热量低，安装便利。
●整体设计科学，结构紧凑，布局合理，现场安装拆卸简单，便于维修、部件更换。
●顶驱工作温度满足-45℃，储存温度满足-60℃
随着业务的发展，天意顶驱团队提供以下服务：
●顶驱的生产和销售
●顶驱租赁业务
●各品牌顶驱的现场技术服务与维修石油相关设备的开发研制。
Top Drive System
Top Drive System is a new-style drilling system, which is used to instead of the rotary table. It is integrated with mechanical, electrical and hydraulic technology and has advanced automation level. It’s called a great revolution in drilling equipment and also gives the direction for drilling equipment development in 21st century. Top Drive System has been the standard equipment in the international drilling industry and is suitable to be used in cluster directional well, high-inclination well and horizontal well, especially deep well and ultra deep well.
Features
●Control technology is with the mechanical, electronic and hydraulic integration; output parameters of frequency converter are matched with the characteristics of the motor; PLC programme can be designed according to the requirement of the customer. It has functions of monitoring, alarming, self-diagnosis, protection and interlocking, which conform to drilling condition.
●Rotating head adopts two ducts to supply oil to tilt hydro cylinder, so link can incline forward and swing backward; as each duck is sealed doubly,the leakage is reduced greatly and the reliability of the equipment is improved; the rotating head can rotate with drilling tools while tripping, so the settlement of the accident is easier. Simple inserted inner housing structure; back-up tong and IBOP oil cylinder don’t rotate with rotating head. Simple inserted inner housing structure; back-up tong and IBOP oil cylinder don’t rotate with rotating head.
●It has double load channels. The bearing of gearbox bears the weight during drilling and the bearing of rotating head bears the weight during tripping, therefore, the service life of bearings and main shaft will be prolonged and anti-vertical vibration of drilling string will be improved.
●L-type backup tong applied is easy for replacing tong head, tong dies, upper&lower IBOP and saver sub
●The hydraulic pump can be turned off while drilling and directional well drilling, thus the service life of the pump will be prolonged. In case that hydraulic system breaks down, drilling and reaming can be continued Integrated hydraulic system and oil tank are placed on the body of the top drive; the system sends out low heat, which is convenient for installation.
●Scientific design, compact structure and reasonable arrangement make onsite maintencance, parts replacement, installation and uninstallation much more easier.
●Top drive operation temperature -45℃,storage temperature-60℃
Main Business:
●Manufacture and sale of TDS
●TDS rental
●Field technical support and repair for other brands of TDS
●Design and manufacture oil equipments
天意顶驱已在国内外普遍应用（已在国内外使用240余部）。国内主要使用区域在中国石油（CNPC）中国石化（SINOPEC）中海油（CNOOC）及其他。
